Product code: P7200004

MATRIX LED 1630

Blinder with sixteen RGBW LEDs with a total power of 30W each. It emits strong light with a long range, emitting a virtually unlimited combination of extremely bright colors. Thanks to its power, it perfectly illuminates every space in which it is located.

Massive construction, high quality workmanship and materials ensuring high durability, making this device a perfect tool for both demanding users and people who value simplicity and reliability.

MATRIX LED 1630 WHITE

Blinders

Product photos whose specifications speak for themselves. Check out what MATRIX LED 1630 looks like in action.

TheflashPROvideo section is a great place to learn about the capabilities of our product. Check what your light can look like! Below are some examples of implementations using MATRIX LED 1630

Power Source (AC)
Supply voltage	100-245V
Power consumption	500W
Power frequency	50-60Hz

Light source
Type	LED (RGBW)
Quantity	16
Power	30W
Color temperature	-
Color Rendering Index (CRI)	87,8

Smooth Color Mixing
RGBW	8 bit
RGBW	16 bit

Darkening
Darkening	8 bit
Darkening	16 bit

Beam angle
Beam angle	Stały (50 ⁰)

Flash - frequency
Frequency	1Hz-20Hz

DMX control
Number of modes	30
Number of channels	3-128

Modes of operation
DMX512	Yes
Sound control	Yes
Auto control	Yes
Master-slave	Yes

User Interface
Physical buttons	Yes
LCD display	Yes

Connectors
AC IN	PowerCON
AC OUT	PowerCON
DMX IN	3-pin DMX
DMX OUT	3-pin DMX

Physical parameters
IP protection level	IP20
Housing type	Aluminium
Fixing	Integrated
Fixing	Mounting hole
Housing color	Black
Cooling	Active
Length [cm]	35,5
Width [cm]	19
Height [cm]	35,5
Weight [kg]	8,6
